Description
Combining the capabilities of an inverter, MPPT solar charger, and battery charger, the SAKO SUNON PRO Serie is a multipurpose inverter/charger that provides uninterruptible power support in a portable package. Depending on the application, its extensive LCD display provides user-configurable, easily accessible buttons for battery charging current, AC/solar charger priority, and allowable input voltage.
Features
- Pure sine wave output
- Built-in MPPT solar charge controller
- MAX PV Array Open Circuit Voltage: 450V
- Overload, short circuit and Deep discharge protection
Solar Energy
Inverter Model
SUNON PRO 3.5K
Rated power
3500VA/3500W
Battery
Battery voltage
24VDC
Low battery alarming voltage
22.0VDC
Low battery cut off protection voltage
21VDC
Low battery recovery voltage
23.0VDC
Floating Charge Voltage
27VDC
Overcharge Protection
32VDC
MPPT SOLAR CHARGER & AC CHARGER
Maximum PV Array Power
5000W
MPPT Range Operation Vol
120-450VDC
Maximum PV Array Open Circuit Vol.
500VDC
Number of MPPT trackers / Max output current
100A
Maxmum AC Charge Current
60A
Maxmum Charge Current
100A
Maximum Efficiency
98%
BEST PANEL CONFIGUTATION
Maximum PV Array Power
5000W
Best Panel configuration
300Wp*9pcs*36V(2700Wp)*2Parallel
Inverter Physical
Products Dimension
Packing size, D*W*H(mm)
543mm*394mm*204mm
G.W. kg
11.2Kg
Inverter Operating Environment
Humidity
5% to 95% Relative Humidity (Non-condensing)
Operation Temperature
0℃-50℃
Inverter INPUT
Voltage
230VAC
Inverter OUTPUT
Surge Power
7000VA
No load current
1.0A
AC Voltage Regulation (Batt. Model)
230VAC ± 5%
